3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making

    Buy cheap 3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making from wholesalers

    Buy cheap 3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making from wholesalers
    • Buy cheap 3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making from wholesalers
    • Buy cheap 3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making from wholesalers
    • Buy cheap 3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making from wholesalers

    3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making

    Ask Lasest Price
    Brand Name : Quanheng
    Model Number : QH-1600-3PLY
    Certification : CE ISO
    Price : Negotiate
    Payment Terms : L/C, T/T
    Supply Ability : 10 SETS/PER YEAR
    Delivery Time : 180 DAYS
    • Product Details
    • Company Profile

    3 PLY Corrugated Cardboard Making Machine Width 1600mm 120m/Min For Paper Box Making

    Hot sell 1600 type 3 PLY Corrugated Cardboard Production Line


    ModelEquipment nameQTY/SetRemark
    YV5BHydraulic shaftless mill roll stand2

    The spindle¢240mm,hyperbola heavy rocker,toothed chuck,multi-disc ventilated disc brakes,hydraulic drive lift,left and right translation,for medium.

    Rail length6000mm,trolley used 10mm plate welding.

    Paper trolley4
    SP-1-600Single Pre-heater (floor)1Roller ¢ 600mm, including pressure vessel certificate. Electric adjustment angle. The wrap angle can adjust the heated area of the paper within 360°.
    320BSingle facer1Corrugated main roll ¢ 320mm, material 48CrMo alloy steel. Independent gearbox, universal joint transmission structure.
    SP-3-600Double preheated1Roller ¢ 600mm, including pressure vessel certificate. Electric adjustment angle. The wrap angle can adjust the heated area of the paper within 360°..
    GM-18glue machine1Diameter of glue roller¢269mm,Frequency independent motor drive,PLC control,Machine interface touch screen display.
    ZDFConveyor bridge1200mm main beam channels, independent inverter motor drive pull paper feed, adsorption tension. Electric correction.
    HPMDouble facer machine1Drying department 14 heating plates, 4 pressure plate, pneumatic lifting pressure roller, using dense pressure roller.
    FTKMElectric adjustment thin blade machine1Electric adjustment knife, electric bias, 5 knife 8-wire type, blade made of tungsten alloy steel.
    NC-S120NC Cut off machine1Full AC servo control, energy storage brake, spiral knife structure, oil-immersed gear drive, 10.4 inch touch screen display.
    SMA-SStacker1Electrically adjust the cardboard size and pneumatically control the lateral output cardboard.
    ZQSteam system1Including equipment pipeline valves, steam traps, meters and other steam components, customer-owned heat sources and pipelines.
    ZJZGlue making system1Pipeline customers bring their own. The glue making device consists of a carrier tank, a main tank, a storage tank, and a glue pump and a back pump.
