Brand Name : | QH |
Certification : | CE ISO |
Price : | USD+100000-230000+1 SET |
Payment Terms : | L/C, T/T |
Supply Ability : | 20 sets per year |
Delivery Time : | 120 days |
Lead Edge Feeder Four Colors Printer Slotter Rotary Die Cutter Folder Glue Bundle Machine
Machine introduce
1. the packaging line is composed of three parts: steering machine, box clapping machine and unmanned dynamic packing machine.
2. Function: this assembly line is a fully automatic packing assembly line with integrated machine, electricity and gas.
3. The main functions are:
(1) Close the box: the carton around and after finishing tidy and leveling;
(2) Packing: packing and exporting the finished cartons.
name | |||
1 | Machine insdie width | mm | 2000 |
2 | Design speed | Pcs/min | 250 |
3 | Economical speed | Pcs/min | 160-200 |
4 | Max feed size | mm | 900×1800 |
5 | Min feed size | mm | 420×1000 |
6 | Max printing size | mm | 900×1600 |
7 | Max die size | mm | 900×1800 |
8 | Die thickness of paperboard | mm | 3-10 |
9 | Skip feed size | mm | 1200×1800 |
10 | pricision | mm | ±1 |
11 | Stardard print plate thickness | mm | 7.2 |
12 | Paperboard thickness | mm | 2--11 |
13 | Min slotter distance | mm | 280*100*280*100(mm) |
14 | Max slotter depath | mm | 450 |
15 | Printint roller adjust(L&R) | mm | ±10 |
![]() |
