Brand Name : | QH-PACK |
Model Number : | CGJ450-3L/650-3L |
Certification : | CE ISO |
Price : | USD 24000-30000 PER SET |
Payment Terms : | L/C, T/T |
Supply Ability : | 10 SETS PER MONTH |
Delivery Time : | 40 DAYS |
CGJ450-3L
Name | Unit | Data |
Horizontal inserting width: A | mm | 120~900 |
Lengthways sheets length: B | mm | 210~450 |
Clapboard Height: C | mm | 85~300 |
Lengthways clapboard distance: D | mm | 20~400 |
Horizontal clapboard distance: E | mm | 45-850 |
Lengthways sheets No. | piece | 1-6 |
Horizontal clapboard No. | piece | 1-21 |
Carton inserting mouth width:F | mm | >board thickness |
Carton thickness:G | mm | 1.5~8mm |
CGJ600-3L
Name | Unit | Data |
Horizontal inserting width: A | mm | 120~900 |
Lengthways sheets length: B | mm | 210~600 |
Clapboard Height: C | mm | 85~300 |
Lengthways clapboard distance: D | mm | 20~500 |
Horizontal clapboard distance: E | mm | 45-850 |
Lengthways sheets No. | piece | 1-6 |
Horizontal clapboard No. | piece | 1-29 |
Carton inserting mouth width:F | mm | >board thickness |
Carton thickness:G | mm | 1.5~8mm |
The testing partition board should meet the following requirements:
* Partition board molding: die cutting molding
* Partition board interval should have bevel/oblique opening
![]() |
